Improvement of water pump

[袁春凤 (Tiffany)]

The most important component of the water pump is the pump shell and the inner parts of bearing and the bearing. To improve the pump, the most important thing is to optimize and improve the two parts. The following is a detailed introduction to the improvement of the two parts.

1. to improve the pump shell. When disassembly the pump to inspect the failure, there are a large number of debris seriously affect the quality of the pump and work efficiency. In this case, we can reduce the two holes used for drainage on the pump shell to one, and remove the drain holes on the upper part of the transmitter. This can greatly reduce the small particles and sundries into the pump, thus greatly reducing the interference of sundries on the pump and the other bad.

2. to improve the bearing. In the case of the failure of the bearing, we are generally sealed, the lubricating oil used by the bearing, the ball of the bearing and the bearing itself. So we should have a solution to these parts

3. to improve gasket. The traditional design is to design the sealing test as a double mouth seal, so the advantage of the design is that two ports are all frictional with the bearing, the roughness of the bearing surface is more appropriate and the wear of the lip is relatively slow; but the disadvantage is that a large amount of dust can be directly entered into the middle of the mouth and bearing, so that the plate will be used for a period of time. The interference between the bearing and the bearing decreases, thus losing the original function of the seal. There are two ways to improve it: the first is the sealing week of the bearing with double, and the sealing area is lengthened properly and the thickness of the chip mouth is thickened accordingly. The method is to change the original double mouth into the three form of the seal and seal the seal. The advantage of this structure is that the outer lip and mouth have increased the seal design, which can resist many dust. However, this method also has shortcomings, the mouth and the reverse cap friction, the surface roughness of the surface of the cover is relatively poor, it is very easy to wear and tear seal test, resulting in sealing failure.

4. to improve the lubricating oil. The bearing of the automobile pump is a more special bearing unit. Its environment is mostly temperature, humidity and dust, and the temperature of the water usually reaches about one thousand degrees, so the lubricating oil of the bearing is required. From our analysis of the fault, the lubricating oil in the bearing of the fault appears discolourable, which means that the grease in the lubricating oil is not enough, so the lubricating oil manufacturer should be required to increase the fat content of the lubricating oil so as to ensure the better protection of the bearing.

5. to Improve the contact ball of the bearing. Balls in bearing are important parts to ensure normal operation of bearings, but there are more and more damage to rolling balls. When measuring the hardness of the ball, it is found that most of the balls do not meet the required hardness requirements, which makes the bearings greatly wear at high speed and finally breaks down completely. Therefore, we should strictly supervise the production quality of the manufacturers, guarantee the hardness of the ball and pass the quality, so that the fundamental problem of bearing damage can be effectively solved.
